GEEKOM IT12 Max Mini PC | Intel® Core™ Ultra 5 125U

Description

Specification

Processor: Intel® Core™ Ultra 5 125U
Graphics: Intel® Arc™ Graphics
Memory: Onboard LPDDR5 16GB
Storage: 1× M.2 2280 PCIe Gen 4×4 NVMe SSD 500GB
Operating System: Windows 11 Pro
Wireless: Wi-Fi 7 + Bluetooth 5.4
Ethernet: 2× 2.5GbE RJ45 (10/100/1000/2500Mbps)
Display Outputs: 2× HDMI 2.0 (up to 4K) + USB4 Display Support
USB4: 1× USB4 Type-C (40Gbps) + 1× USB4 Type-C with PD Input (up to 100W)
USB: 5× USB 3.2 Gen 2 Type-A + 1× USB 2.0 Type-A
Card Reader: 1× SD 4.0 Card Reader
Audio: 1× 3.5mm Headphone Jack
Power: 120W (19V / 6.32A)
VESA Mount: Supported
Dimensions: 137 × 132 × 57.8 mm

Connectivity Highlights

Dual 2.5GbE LAN
High-speed wired connectivity

Wi-Fi 7 + Bluetooth 5.4
Next-generation wireless connectivity

USB4 40Gbps
High-speed data and display connectivity

USB-C PD Input
Up to 100W Power Delivery input

Dual HDMI
Flexible multi-display connectivity

What’s in the Box

1× GEEKOM IT12 Max Mini PC
1× VESA Mount
1× Power Adapter
1× HDMI Cable
1× User Manual
1× Thank You Card
